ENGLISH
UPS EVO DSP PLUS Modular 35 User’s manual
5.2.5.4 SETUP-PRE-ALARM Submenu
The SETUP-PRE-ALARM Screen and Setting options are shown in Figure 5.18.
SETUP-PRE-ALARM Setting can be set in any operation Mode.
Please check Table 5-10 “SETUP-PRE-ALARM Setting List” for the details.
Figure 5.18 - SETUP-PRE-ALARM Screen
Table 5-10: SETUP-PRE-ALARM Setting List
Setting Item
Sub Item
Explanation
Line Voltage
Range
--
Set Line Voltage Range.
Upper limit:
• +5%
• +10%
• +15%
• +20 (Default)
Lower limit:
• -5%
• -10%
• -15%
• -20 (Default)
Line
Frequency
Range
--
Set Line Frequency Range.
Upper / Lower limit:
• +/- 1Hz
• +/- 2Hz
• +/- 3 Hz
• +/- 4Hz (Default)
Load
--
Set UPS Overload Percentage (40~100%):
• 100% (Default)
Set UPS Load Unbalanced Percentage (20~100%):
• 100% (Default)
