ENGLISH
User’s manual 34 UPS EVO DSP PLUS Modular
Table 5-9: SETUP-BATTERY Setting List
Setting Item
Sub Item
Explanation
Nominal
Battery
Voltage
--
Set Battery Nominal Voltage:
• 16 x 12 V
• 18 x 12 V
• 20 x 12 V (Default)
MUST be set after UPS installation
Battery
Capacity (Ah)
--
Set Battery Capacity (up to 999Ah).
MUST be set after UPS installation or Battery capacity is changed.
Maximum
Charging
Current
--
Set battery maximum charging current (1~128A).
MUST be set after UPS installation or Battery capacity is changed.
Battery Low /
Shutdown
Setting
Low Voltage
Set Battery Low Voltage (10.5~11.5V) x (Battery Number):
• 11V x Battery Number (Default)
Low Capacity
Set Battery Low Capacity (20~50%):
• 20% (Default)
Shutdown
Voltage
Set Battery Voltage point for System Shutdown in Battery Mode
(10.5~11,5V) x (Battery Number):
• 10V x Battery Number (Default)
Battery Test
Periodic Battery
Test
Set Periodic Battery Test:
• Disable (Default)
• Enable
Battery Test
Interval
Set Battery Test Interval (7~99 Days):
• 30 Days (Default)
Stop by Time
Set Testing Time for Battery Test (10~1000 sec):
• 10 sec (Default)
Stop by Battery
Voltage
Set Stop Battery Voltage in Battery Test (11~12V) x (Battery Number):
• 11V x Battery Number (Default)
Stop by Battery
Capacity
Set Battery Capacity to Stop Battery Test (20~50%):
• 20% (Default)
Battery Age
Alert
Battery Age Alert
(Months)
Set Battery Age for replacement (Disable,12~60 Months):
• Disable (Default)
If this feature is enabled and the battery has been installed over this
period, there is a warning “Battery Age Alert” to indicate it.
Temperature
Compensation
--
Set Battery Temperature Compensation (0~-5 (mV/°C)):
• 0 (mV/°C) (Default)
Charging
Voltage
--
Set Battery Charging Voltage (2.30~2.35V):
• 2.35V (Default)
Set Battery Float Voltage (2.23~2.35V):
• 2.29V (Default)
Auto-Restart
Battery
Voltage
--
Set Auto-Restart Battery Voltage (0 or 12.0V~13.0V):
• 0V (Default)
