Table 5-8: SETUP-SYSTEM Setting List
Set Bypass Voltage Range.
Set Bypass Frequency range.
If you need the Bypass power when UPS is OFF, please enable it.
After “Enable” is set, once UPS shutdown occurs due to low battery and
then utility restores, the UPS will return to Line Mode.
After “Enable” is set, the UPS can be turned on without connecting to
utility by pressing BATTERY START Button. Refer to chapter 11.2 “Cold Start
Startup” for the details.
Set System Shutdown Delay Time in Battery Mode (0~9990 sec):
When this feature is enabled, UPS will shut off output after UPS operates in
Battery Mode for certain seconds.
Set System Shutdown Time (0.2~99 min):
• 0.2 min (Default)
This delay time will start counting when the CONTROL-Shutdown command
is executed.
Set System Restore Time (0~9999 min)
• 1 min (Default)
This delay time will start counting after shutdown time is elapsed when the
CONTROL-Shutdown Restore command is executed.
The 30K cabinet can be inserted with all 20KVA power modules. For this
kind of application, the Power Rating has to be set to 20KVA. If setting is
not corresponding to power capacity of power module, it will show error
message.
Set Total Power and Redundancy
Total Power: the QTY of Power Modules
Redundancy: the QTY of Redundant Power Modules
MUST be set after UPS installation or the QTY of Power Module is
changed.
