4.4. String Record
Figure 22. V.A String record
display V DC ,V AC measurement
display V ripple ,A DC, A AC measurement
indicates Range of measurement 1 .
In DC voltage & DC current mode, press
for a long time to change Auto / Manual.
Press for a short time to change DC Voltage in order .
indicates Range of measurement 2
In Ampere range, press key to change
indicates number of record saved in the unit.
In String mode, can save upto 512 per string
indicates present Set Up status of measurement function
AutoHold is displaying during in the mode
Auto Record is displaying during in the mode.
indicates when present measurement is in holding
Present measurement data of measurement 1 is displaying in
smaller size
indicates Selected String by user.
saved to Selected String.
