Tekon 950 - Record; Description; Check Used Memory

USER MANUAL
29
5. Record
5.1. Description
The Unit has following Saving Space structure
 Record saves Impedance , Voltage, Temperature and Measurement time ,
 Record saves Measurement 1, Measurement 2, Measurement time
 Meter mode saves max 1000 measurements in record , record
 String mode saves max 250 Strings.
 Listed String used in , .
 Each String can save 60 time Battery series in record. .
Each string record measurement saves as number of Cells (max 512 )
 Each string save max 512 record.
[Refer below table]
Meter
mode
max 1000 measurements
max 1000 measurements
String
001
~250
String 001
1st measurement
(Slot)
Cell 001
……
Cell 512
……
60th measurement
(Slot)
Cell 001
……
Cell 512
String 001
REC 001
……
REC 512
5.1.1. Check Used Memory
To check used Memory, press to display percentage(%) of remaining memory at the upper
middle display .
When Unit is Power On, Message about remaining memory is displayed.
