Tektronix AFG31000 Series User Manual

Function introduction
146 AFG31000 Series Arbitrary Function Generator User's Manual
4. Copy. It is used to copy a piece of waveform data between the two cursors. The waveform will not
be changed.
5. Paste.
Item Description
Paste at the End
Paste a waveform segment at the end of a waveform
Paste at the Beginning
Paste a waveform segment at the beginning of a waveform
Paste at the Active Cursor
Paste a waveform segment behind an active cursor.
Replace between the
Cursors
Replace the waveform between the cursors by a waveform segment
6. Invert. It is used to overturn the waveform between the cursors in the vertical direction.
Figure 142: ArbBuilder invert
Figure 143: ArbBuilder invert final
