Tektronix AFG31000 Series User Manual

Function introduction
AFG31000 Series Arbitrary Function Generator User's Manual 149
Table 13: Controls for modifying a waveform
Item Description
Points
Set the point number which is moved each time
Amplitude
Set the amplitude which is moved each time
Rotate
Move the waveform periodically
Horizontal Shift
Move the waveform and use zero to fill the data after the waveform
 Shift left is used to move the waveform left.
 Shift right is used to move the waveform right.
 Shift up is used to move the waveform up.
 Shift down is used to move the waveform down.
Figure 147: ArbBuilder shift rotate
