AFG31000 Series Arbitrary Function Generator User's Manual 45
Power the instrument
The following procedure shows you how to connect the instrument to power and turn it on and off.
Connect the power cord:
1. Make sure the front-panel power switch is in the off position
2. Connect the female end of the supplied power cord to the AC receptacle on the rear panel.
3. Connect the male end of the power cord to a grounded AC outlet.
To power on the instrument
1. Press the front-panel power switch to turn on the instrument.
Figure 18: AFG31000 Series two-channel front view
NOTE. Wait until the front-panel display shows that the instrument has passed all power-on self-tests
before using the instrument.
Section
Operating basics
