Analyze Wavefor

mData

Search Description

Rise/Fall Tim

Search for ris

ing and/or falling edges that are >, <, =, or ≠ a user speciﬁed time.

Bus

Parallel: S e a

rch for a binary or hex value (MSO4000B Series only).

C: Search for Start, Repeated Start, Stop, Missing Ack, Address, Data, or Address and

Data.

SPI: Search f

or SS Active, MOSI, MISO, or MOSI & MISO

RS-232, RS-422, RS-485, UART: Search for Tx Start Bit, Rx Start Bit, Tx End of Packet, Rx

End of Packet, Tx Data, Rx D ata, Tx Parity Error, Rx Parity E rror

CAN: Search

for Start of Frame, Type of Frame (Data, Remote, Error, Overload), Identiﬁer

(standard or extended), Data, Identiﬁer and Data, End of Frame, or Missing Ack, Bit Stufﬁng

Error

LIN: Searc

h for Synch, Identiﬁer, Data, ID & Data, Wakeup Frame, Sleep Frame, Error

FlexRay: Search for Start of Frame, Type of Frame, Identiﬁer, C ycle C ount, Header Fields,

Data, ID & Data, End of Frame, Error

Audio: Sea

rch for Word Select or Data

USB: Search for Sync, Reset, Suspend, Resume, End of Packet, Token (Address) Packet,

Data Packet, Handshake Packet, Special Packet, or Error

Ethernet

: Search for Start of Frame, MAC Addresses, MAC Length/Type, MAC Client

Data, End of Packet, Idle, FCS (CRC) Error. If Q-(VLAN) Tagging is turned on, you c an

also search for Q-Tag Control Information.

MIL-STD

-1553: Search for Sync, Command, Status, Data, Time (RT/IMG), Error

132 MSO4000B and DPO 4000B Series Oscilloscopes User Manual
