Tektronix MSO4104B User Manual

Appendix C: P661
6 General-Purpose Logic P robe Information
Specifications
Table 9: Electrical and mechanical specifications
Characteristic Description
Input channels 16 digital
Input resist
ance
100 kΩ ±1.0%
Input capac
itance
3.0 pF
Input signal swing
Minimum 400 mV p-p
Maximum
30Vp-p,≤200 MHz (centered around the DC threshold voltage) at the
probe tip
10Vp-p,≥
200 MHz (centered around the DC threshold voltage) at the
probe tip
Maximum n
ondest–
ructive input signal
±42 V
User defined threshold range
±40 V
Minimum
detectable pulse width
1ns
Digital channel-to-
digita
l channel skew
200 ps
Probe length
1.3 m (4
.27 ft)
Maximum input toggle rate 500 MHz
Table 10: Environmental s pecifications
Char
acteristic
Desc
ription
Temperature
Operating 0 °C to +50 °C (+32 ° F to +122 °F)
Nonoperating
–55 °C to +75 °C (–67 °F to +167 °F)
Humidity
Operating 5% to 95% relative humidity
N
onoperating
10% to 95% relative humidity
A
ltitude
Operating 4.6 km (15,092 ft) maximum
Nonoperating
15 km (50,000 ft) maximum
Equipment Recycling. This product complies with the European Union’s requirements according to Directive
2002/96/EC on waste electrical and electronic equipment (WEEE). For more information about recycling
options, check the Support/Service section of the Tektronix Web site (www.tektronix.com).
202 MSO4000B and DPO 4000B Series Oscilloscopes User Manual
