Tektronix MSO4104B User Manual

Appendix A: MSO/
DPO4000B Warranted Specifications
Appendix A: M S
O/DPO4000B Warranted Specifications
You can find a more c omplete list of MSO4000B and DPO 4000B product specifications in the MSO4000B and DPO4000B
Series Oscilloscopes Technical Reference.
Table 2: Analog channel input and vertical specifications
Characteristic Description
1MΩ 1MΩ ±1%
50 Ω ±1%
MSO4104B,
MSO4104B-L,
MSO4102B,
MSO4102B-L,
DPO4104B,
DPO4104B-L,
DPO4102B,
DPO4102B-L
VSWR ≤1.5:1 from DC to 1 GHz, typical
MSO4054B,
DPO4054B
VSWR ≤1.5:1 from DC to 500 MHz, typical
MSO4034B,
DPO4034B
VSWR ≤1.5:1 from DC to 350 MHz, typical
Input
impedance, D
C
coupled
50 Ω
MSO4014B,
DPO4014B
VSWR ≤1.5:1 from DC to 100 MHz, typical
Input
Capacitance, 1 MΩ
DC coupled
13 pF ± 2 pF
DC Balance
0.1 div with the input DC 50 Ω coupled and 50 Ω terminated
0.2 d
iv at 1 mV/div with the input DC 50 Ω coupled and 50 Ω terminated
0.2 div with the input DC 1 MΩ coupled and 50 Ω terminated
For 50 Ω path:
±1.5%, derated at 0.050%/°C above 30 °C
±3.
0% variable gain, derated at 0.050%/°C above 30 °C
Fo
r1MΩ, 250 KΩ path:
±2.0%, derated at 0.100%/°C above 30 °C, 1 mV/Div setting
±1.5%, derated at 0.100%/°C above 30 °C
±3
.0% variable gain, derated at 0.100%/°C above 30 °C
MSO4104B,
MSO4104B-L,
MSO
4102B,
MSO4102B-L,
DPO4104B,
DP
O4104B-L,
DPO4102B,
DPO4102B-L
(
250 KΩ path checked indirectly.)
F
or 50 Ω path, 1MΩ, and 250 KΩ path:
±2.0%, derated at 0.100%/°C above 30 °C, 1 mV/Div setting
±1.5%, derated at 0.100%/°C above 30 °C
±3.0% variable gain, derated at 0.100%/°C above 30 °C
DC gain
accuracy
M
SO4054B,
DPO4054B,
MSO4034B,
DPO4034B,
MSO4014B,
DPO4014B
(250 KΩ path checked indirectly.)
MSO4000B and DP O4000B Series Oscilloscopes User Manual 187
