Appendix A: MSO/
DPO4000B Warranted Specifications
Table 2: Analog channel input and vertical specifica tions ( cont.)
Characteristic Description
Offset accuracy
±[0.005 × | offset – position | + DC Balance]
Both the position and constant offset term must be converted to volts by multiplying by the
appropriate volts/div term.
Full bandwidth, with amplitude tolerance of -3 d B and operating temperatures of ≤30 °C (86 °F).
Reduce the bandwidth by 1% for each °C above 30 °C.
Instrument
Volts/Div setting
Bandwidth
5 mV/div – 1 V/div DC to 1.00 GHz
2 mV/div – 4.98 mV/div DC to 350 MHz
MSO4104B,
MSO4104B-L,
MSO4102B,
MSO4102B-L,
DPO4104B,
DPO4104B-L,
DPO4102B,
DPO4102B-L
1 mV/div – 1.99 mV/div DC to 175 MHz
5 mV/div – 1 V/div DC to 500 MHz
2 mV/div – 4.98 mV/div DC to 350 MHz
MSO4054B,
DPO4054B
1 mV/div – 1.99 mV/div DC to 175 MHz
2 mV/div – 1 V/div DC to 350 MHzMSO4034B,
DPO4034B
1 mV/div – 1.99 mV/div DC to 175 MHz
Analog
bandwidth, 50 Ω,
DC coupled
MSO4014B,
DPO4014B
1 mV/div – 1 V/div DC to 100 MHz
Full bandwidth, with amplitude tolerance of -3 d B and operating temperatures of ≤30 °C (86 °F).
Reduce the bandwidth by 1% for each °C above 30 °C.
Instrument
Volts/Div setting
Bandwidth
5 mV/div – 10 V/div DC to 500 MHz
2 mV/div – 4.98 mV/div DC to 350 MHz
MSO4104B,
MSO4104B-L,
MSO4102B,
MSO4102B-L,
DPO4104B,
DPO4104B-L,
DPO4102B,
DPO4102B-L
1 mV/div – 1.99 mV/div DC to 175 MHz
5 mV/div – 10 V/div DC to 500 MHz
2 mV/div – 4.98 mV/div DC to 350 MHz
MSO4054B,
DPO4054B
1 mV/div – 1.99 mV/div DC to 175 MHz
2 mV/div – 10 V/div DC to 350 MHzMSO4034B,
DPO4034B
1 mV/div – 1.99 mV/div DC to 175 MHz
Analog
bandwidth, 1 MΩ,
DC
coupled
MSO4014B,
DPO4014B
1 mV/div – 1 V/div DC to 100 MHz
188 MSO4000B and DPO 4000B Series Oscilloscopes User Manual
