Save and Recall I
nformation
Save
Setup
To File
Edit Labels
3. From the resul
ting side menu, select the
location to save the setup to or to recall it
from.
To save setup i
nformation to one of the ten
internal setup memories in the oscilloscope,
push the appropriate side button.
To save setup
informationtoaUSBor
network drive, push the To File button.
To Setup 1
To Setup 2
–more–
4. IfyouaresavinginformationtoaUSBor
network dr
ive, turn multipurpose knob a
to scroll through the file structure. (See
page 140, External file s tructur e .)
Push Select to open or close file folders.
Push the Menu Off button to cancel the
save operation, or push a Save to Selected
File choice to complete the operation.
146 MSO4000B and DPO 4000B Series Oscilloscopes User Manual
