Application Exa
mples
5. Push Trigger Me
nu.
6. Push Slope and .
7. Turn the Trigger Level knob to adjust
the trigger level to a voltage midway
between the open and closed voltages
of the replay.
8. Push Single (single sequence).
MSO4000B and DP O4000B Series Oscilloscopes User Manual 177
