MX32v2
ANALOG AND DIGITAL CONTROLLER
USER MANUAL
6
NP32V2EN
Revision D.0
Figure 2: Example of an MX32v2 configuration using different analog
and digital detectors as well as digital modules
MX32v2
Configuring PC with the COM
32 application
Digital detectors
2 logic
inputs
Analog recorders
Four 4-
20mA Analog
Output Module
8 Relay Output Module
Logic Input Module
4 Relay Output
Module
16 logic inputs
Analog inputs
E
xternal power
supply
USB
link
8 Analog Input Module
