11.4 8-Analog Input Module
Function
Function 4-20mA detector or Wheatstone bridge connections
Capacity
1 to 8 independent inputs
Terminals
■ Screw terminals. Can accept 2.5 mm² (14AWG) wire
■ Removable terminal without powering the line down
Consumption 53 mA max (detector excluded)
Assembly
DIN rail mounted
Dimensions
125 x 165 x 60 mm
11.5 4-Analog Output Module
Function
Function Generation of 1 to 4 analog values
Capacity
■
4 4-20mA discrete opto-isolated outputs (recopy detector,
minimum, maximum, or average of a detector group)
■ Resistance of maximum load 500 Ω
Logic inputs 2 additional logic inputs (dry contacts)
Terminals
■ Screw terminals. Can accept 2.5 mm² (14AWG) wire
■ Removable terminal without powering the line down
Consumption:
■
< 5 mA with the 4 lines at stop
■ < 36 mA for an activated line
■ < 130 mA for the 4 activated lines
Assembly
DIN rail mounted
Dimensions
125 x 165 x 60 mm
