5 Digital Modules
This chapter presents the digital modules that may be installed on the MX32v2 lines.
The details of module connection are given on page 33.Digital modules are
configured via COM 32 configuration software.
5.1 Addressable Digital Modules
Up to 5 modules can be used with the single line version and up to 10 modules can be used
with the 2 line models. The MX32v2 in bridge version is not compatible with any modules (see
Table 1:). The following table lists the available modules:
Type of module
Illustration
Page
4 Output Relay Module with 2 additional logic inputs 24
8 Output Relay Module with 2 additional logic inputs 24
8 Analog Input Module 28
16 Logic Input Module 26
4 Analog Output Module with 2 additional logic inputs
30
Table 4: Addressable digital modules
