TELEDYNE OLDHAM SIMTRONICS MX32 - Relay Module Specifications; Logic Input Module Specifications

MX32v2
ANALOG AND DIGITAL CONTROLLER
USER MANUAL
66
NP32V2EN
Revision D.0
11.2 Relay Module
Function
Function Management of 4 or 8 relays from the digital signals issued by
the MX32v2
Number of relays
■
4 or 8 relays
■ DPCO contact relays
Relay type
■
Bistable
■ Energized or de-energized configuration by DIP switches
■ Setting of relay parameters by COM 32 application
Nominal load of contacts 2A/250Vac-30Vdc
Consumption 3.5 mA in normal operation
Terminals
■
Screw terminals. Can accept 2.5 mm² (14AWG) wire
■ Removable terminal without powering the line down
Logic inputs 2 additional logic inputs (dry contacts)
Assembly DIN rail mounted
Dimensions 125 x 165 x 60 mm
11.3 16-Logic Input Module
Function
Function
Logic input monitoring
Capacity 1 to 16 logic inputs (dry contacts)
Terminals
■
Screw terminals. Can accept 2.5 mm² (14AWG) wire
■ Removable terminal without powering the line down
Consumption
2 mA in normal operation
Assembly
DIN rail mounted
Dimensions 125 x 165 x 60 mm
