7 Menus
7.1 General Menu Tree
The following figure shows the general tree of the group of menus.
See page 42
↓
See page 44
↓
↓
↓
1 SYSTEM 2 PROGRAM 3 CALIBRATION
See page 44 See page 45 See page 45
↓
↓
4 MAINTENANCE 5 INFORMATION
See page 49
See page 50
Figure 34: General menu tree of the MX32v2
