6 Wiring and Electrical Connections
This chapter details the electrical connections of all components of the system (MX32v2,
modules, additional equipment).
6.1 Controller Connection
The electrical connections must be carried out by qualified personnel in compliance with the
different directives in force in the country of installation.
The
MX32v2
does not have a start/stop switch.
Certain voltage levels are capable of causing serious injuries or even death. It is
advised to install the material and cabling before applying live voltage.
Since an incorrect or poor installation may cause measurement errors or system
failures, it is necessary to strictly follow all the instructions in this manual in order to
guarantee the proper operation of the system.
Certified strain relief bushing required. Utilized cords shall comply with all certified
bushing specifications.
Suitable external cords shall be used in the end application and shall be according to
local rules/standards for
MX32v2
product.
Cables with an operating temperature of 70°C minimum (158 °F) must be used
because the temperature inside the controller can reach 70°C (158 °F).
6.1.1 Access to terminal blocks
After unlocking the two toggle latches, swing the front cover towards the left in order to access
the wiring terminal.
6.1.2 100-240 Vac Power Supply
The
MX32v2
can be powered from a 100-240Vac source at 50/60 Hz, 1.5A max. Check the
nature of the current and the voltage value prior to any connection. The electrical connections
must be carried when power is down.
A bipolar differential circuit breaker, 4A, type C, must be included in the installation as means
for disconnection. It must be suitably located and easily reached and must be marked as the
disconnecting device for the
MX32v2
.
