MX32v2
ANALOG AND DIGITAL CONTROLLER
USER MANUAL
NP32V2EN
Revision D.0
19
(a): Automatic deactivation upon alarm disappearance even if Alarm Reset button was not
pressed
(b): Manual acknowledgement (press Alarm Reset) is mandatory to silence the internal buzzer
Table 2: Alarms in Automatic Acknowledgement mode
4.3.4 Alarms Manual Acknowledgement
In this mode, Alarms must be reset by the operator. Alarm management (relays, visual
indicators, buzzer) is as follows:
Event
Display
Alarm Relay
(normal mode)
Alarm Relay
(buzzer mode)
Alarm LED
Internal
buzzer
Alarm
Appearance
AL(1,2,3)
grayscale
mode
Activated Activated Blinking ON
Alarm Reset is
pressed
AL(1,2,3)
grayscale
mode
Activated if
event
is still
present
Deactivated
Solid if event is
still present
OFF
AL(1,2,3)
grayscale
mode
Deactivated if
the event has
disappeared
Deactivated OFF if the
event has
disappeared
OFF
Alarm
Disappearance
Normal
mode
(a)
Deactivated
(a)
Deactivated
(a)
OFF
(a)
OFF
(a)
(a): Once Alarm Reset button has been pressed
Table 3: Alarms in Manual Acknowledgement mode
4.4 Firmplate
Firmplates are attached on the right side, on the top and behing the front cover of the MX32v2 .
Following information can be found:
• Model (1 or 2 lines and power supply type)
• Electrical Specifications (power consumption, fuse)
• P/N and S/N
• Warnings and Approval Markings
• Logo and manufacturer’s details
