4 The MX32v2 Controller
4.1 Overview of the Unit
External view
080
Rep.
Function
Rep.
Function
A.
Monochromatic, back-lit graphic
LCD display
F.
Toggle Latch (one is lockable)
B. Zone 1 status indicator G. Power On/Off indicator
C. Zone 2 status indicator H. Failure/maintenance indicator
D.
Integrated siren (option)
J.
Contextual soft keys
E.
Integrated flash (optional)
K.
Alarm Acknowledgement button
Figure 7: External view of the wall-mounted and rack-mounted versions
