MX32v2
ANALOG AND DIGITAL CONTROLLER
USER MANUAL
Revision D.0
Internal view
Figure 8: Internal view (2 line version on top and Bridge version at the bottom)
A. LCD graphic display card
B. USB programmation port
C. On-board additional flashlight (option)
D. Programming (or mode) selector
0.
MX32v2
in normal operation.
1. Read/Write configuration program
2.
MX32v2
firmware update via a PC
To Next Page
