MX32v2
ANALOG AND DIGITAL CONTROLLER
USER MANUAL
Revision D.0
C – Module configuration DIP switchesThese switches are set according to the following
table:
Slave number
Numéro esclave
See details in the paragraph
Module Address
on page 22
Frame filling
Remplissage de trame
Factory settings. Do not modify
Temporisation
Factory settings. Do not modify
E.O.L. Resistor
Résistance F.D.L.
See details in paragraph
End of line Resistor,
on page 24
Table 9: Analog Output Module Configuration DIP switches
5.7.2 Connection
Refer to Chapter 6, on page 33
5.7.3 Configuration
Configured via the
COM 32
application
