Module
Address
DIP switches
(ON = 1; OFF = 0)
M odule
Address
DIP switches
(ON = 1; OFF = 0)
1
2
3
4
5
1
2
3
4
5
1
1 0 0 0 0
17
1 0 0 0 1
2
0 1 0 0 0
18
0 1 0 0 1
3
1 1 0 0 0
19
1 1 0 0 1
4
0 0 1 0 0
20
0 0 1 0 1
5
1 0 1 0 0
21
1 0 1 0 1
6
0 1 1 0 0
22
0 1 1 0 1
7
1 1 1 0 0
23
1 1 1 0 1
8
0 0 0 1 0
24
0 0 0 1 1
9
1 0 0 1 0
25
1 0 0 1 1
10
0 1 0 1 0
26
0 1 0 1 1
11
1 1 0 1 0
27
1 1 0 1 1
12
0 0 1 1 0
28
0 0 1 1 1
13
1 0 1 1 0
29
1 0 1 1 1
14
0 1 1 1 0
30
0 1 1 1 1
15
1 1 1 1 0
31
1 1 1 1 1
16
0 0 0 0 1
32
0 0 0 0 0
Table 5: Addressing table (address depends on the position of the switches)
Remarks:The physical address of a module (1 to 32 max) must be identical to the registered
address via COM 32 software configuration.
• When a module has to be replaced, all DIP switches must be configured as the previous
module.
• Switch #6 (FRAME FILLING/REMPLISS TRAME) must be set to OFF and switch #7
(DELAY/TEMPORISATION) must be set to ON (options unused).
• The 8 analog input module systematically monopolizes 8 addresses.
