MX32v2
ANALOG AND DIGITAL CONTROLLER
USER MANUAL
Revision D.0
A – Logic input terminalsEach of these two terminals may be connected to a voltage-free
contact as per Erreur ! Source du renvoi introuvable..
B – Module configuration DIP switchesThese DIP switches are set according to the following
table.
Slave number
Numéro esclave
See details in the paragraph
Module Address
on page 22.
Frame filling
Remplissage de trame
Factory settings. Do not modify.
Delay
Temporisation
Factory settings. Do not modify.
Résistance F.D.L.
See details in paragraph
End of line Resistor,
on page 24.
Table 6:
Relay module
configuration DIP switches
C – Relay configuration DIP switchesThe DIP switches allow to choose between normally
energized relay (the coil is energized when not in alarm) or normally de-energized relay (the
coil is energized when in alarm). Set the switch to ON for energized relay or OFF for de-
energized relay. Each switch drives the relay having the same number (switch #1 acts on relay
#1). The contacts are represented with the module not powered.
Re the 4 relay module, only switches #1 to #4 are active.
E – Programmable relays
The 2 line
MX32v2
model can manage up to 16 external relays (limited to 4 relay output
modules). The relays are individually programmable. The operation of each relay depends on
its configuration.
Each detector event [AL1 - AL2 - AL3 – OVS – UDS – Failure] can control one or several
relays. Several events can be assigned to the same relay.
Setting of relay parameters
Relays are to be configured via the
COM 32
configuration software.
• Normal: Relay operation as per the normal management of an alarm (the relay follows
the alarm event))
• Buzzer function (resettable relay): Mainly used for sounder activation. Buzzer operates
as a normal relay; however it can be reset even if the alarm is still present (in order to
turn off the audible alarm). The different time delays are:
. Reset Inhibit: minimum time of activation, adjustable from 0 to 900 seconds
. Automatic reset: If activated, the time is adjustable between 15 and 900 seconds, beyond
which the relay is automatically deactivated
