TELEDYNE OLDHAM SIMTRONICS MX32 - Module Technical Data

MX32v2
ANALOG AND DIGITAL CONTROLLER
USER MANUAL
64
NP32V2EN
Revision D.0
Electrical characteristics
AC power supply
■
100 to 240Vac, 50/60 Hz
■ Maximum 24Vdc output current 1.5A with derating (see next
page)
DC power supply
■
22 to 28Vdc
■ Maximum power consumption 3.5A @ 24Vdc. 1.5A per line and
rest is for controller consumption
Mechanical characteristics
Installation
■
Wall-mounted format. Indoors use only.
Dimensions (wxhxd)
■
265 x 266 x 96 mm (10.4 x 10.5 x 3.8 inches)
Weight
■
1,8 kg (3,97 Lbs)
Ingress Protection
■
IP55
Locking
■ 2 toggle latches (one can be locked)
Environmental characteristics
Temperature of use
-20 to +50°C, -4°F to +122°F (depending on power
consumption)
Storage temperature -20 to +50°C, -4°F to +122°F
Humidity
5 to 95% relative humidity, non codensing
Pressure, Altitude
Atmospheric pressure +/-10%. 2000m max altitude.
Storage
1 year then risk of data loss and memory time loss
Standards
ATEX Performance according to EN 60079-29-1:16
SIL SIL 1 according to EN 50271:2010
Electromagnetic
Compatibility
as per EN50270:15, industrial type 2
Low Voltage Directive as per EN61010-1:10
CSA CAN/CSA-C22.2 No. 0-10; CAN/CSA-C22.2 No. 61010-1-
12; UL Std. No. 61010-1 (3rd Edition)
