Telemark ST Series - 2 Specifications; St Power Supply Models; Figure 2-1, ST Power Supply Part Numbers

ST Series Power Supply Instruction Manual SPECIFICATIONS
telemark.com 15 of 64 Rev 1.0.0
2 SPECIFICATIONS
2.1 ST POWER SUPPLY MODELS
Figure 2-1, ST Power Supply Part Numbers
*An alternative to the standard ST-6 Power Supply. Max HV is reduced to -8kV, but emission is increased to 750mA
Part Number
Description
Output HV and Emission ranges
107-9941-1
ST-4 Power Supply, Cheetah, 208V
HV: 0 to -8kV; Emission: 0 to 500mA
107-9944-1
ST-4 Power Supply, Cheetah, 400V
HV: 0 to -8kV; Emission: 0 to 500mA
107-9951-1
ST-6* Power Supply, Cheetah, 208V, 8kV
HV: 0 to -8kV; Emission: 0 to 750mA
107-9954-1
ST-6* Power Supply, Cheetah, 400V, 8kV
HV: 0 to -8kV; Emission: 0 to 750mA
107-9961-1
ST-6 Power Supply, Cheetah, 208V, 10kV
HV: 0 to -10kV; Emission: 0 to 600mA
107-9964-1
ST-6 Power Supply, Cheetah, 400V, 10kV, CE
HV: 0 to -10kV; Emission: 0 to 600mA
107-9981-1
ST-8 Power Supply, Cheetah, 208V
HV: 0 to -10kV; Emission: 0 to 800mA
107-9984-1
ST-8 Power Supply, Cheetah, 400V, CE
HV: 0 to -10kV; Emission: 0 to 800mA
107-9991-1
ST-10 Power Supply, Cheetah, 208V
HV: 0 to -10kV; Emission: 0 to 1000mA
107-9994-1
ST-10 Power Supply, Cheetah, 400V, CE
HV: 0 to -10kV; Emission: 0 to 1000mA
