Telemark ST Series - Electrical Specifications; Figure 2-6, ST Electrical Specifications

ST Series Power Supply Instruction Manual SPECIFICATIONS
telemark.com 20 of 64 Rev 1.0.0
2.3 ELECTRICAL SPECIFICATIONS
Parameter
ST-4
208VAC
ST-4 CE
400VAC
ST-6
208VAC
ST-6 CE
400VAC
Line Voltage
198-220VAC
380-420VAC
198-220VAC
380-420VAC
Line Frequency
50/60Hz
50/60Hz
50/60Hz
50/60Hz
Line Current
16A
9A
23A
12A
Output Voltage
0 to -8kV
0 to -8kV
0 to -10kV
(optional 0 to -8kV)
0 to -10kV
(optional 0 to -8kV)
Max Output Ripple
0.5%rms
0.5%rms
0.5%rms
0.5%rms
Voltage Regulation
0.2%
0.2%
0.2%
0.2%
Emission Current
500mA
500mA
600mA
(-8kV option is
0 to -750mA)
600mA
(-8kV option is
0 to -750mA)
Filament Current *
0 to 40A
0 to 40A
0 to 40A
0 to 40A
Parameter
ST-8
208VAC
ST-8 CE
400VAC
ST-10
208VAC
ST-10 CE
400VAC
Line Voltage
198-220VAC
380-420VAC
198-220VAC
380-420VAC
Line Frequency
50/60Hz
50/60Hz
50/60Hz
50/60Hz
Line Current
30A
15A
37A
20A
Output Voltage
0 to -10kV
0 to -10kV
0 to -10kV
0 to -10kV
Max Output Ripple
0.5%rms
0.5%rms
0.5%rms
0.5%rms
Voltage Regulation
0.2%
0.2%
0.2%
0.2%
Emission Current
800mA
800mA
1000mA
1000mA
Filament Current *
0 to 40A
0 to 40A
0 to40A
0 to 40A
Figure 2-6, ST Electrical Specifications
* All ST Power Supplies are also available with optional 50A maximum filament current
supplies – please contact Telemark if 50A output current is required
Specifications subject to change without notice
NOTE: The above specified line currents are average maximum
currents at full load and at lowest specified line voltage.
It is considered good practice to select slow blow circuit breakers (or
fuses) with at least one step up in current rating (e.g. +5A). Line feed
cable size must be chosen accordingly.
