75 MPH200 series video encoders CLI user manual
Command line interface - CLI
General
The MPH series video encoder unit includes a command line interface
(CLI) for conguration purposes. The CLI is a screen interface that
allows the user to interact with the operating system by entering com-
mands and optional arguments.
The MPH supports CLI over UART (RS-232), Telnet and SSH.
CLI is accessed through any terminal emulator application. The com-
mand structure is the same for all session types.
Note! PuTTY is a free and open source terminal emulator applica-
tion which can act as a client for the SSH, Telnet, rlogin, and raw
TCP computing protocols and as a serial console client. Tera Term
has comparable features to PuTTY. Hyper Terminal is not
included in Windows Vista or later.
The CLI can be accessed in the following ways:
• Serial data connection (RS232), via Data 2 port, with a serial
connection cable.
• TCP/IP connection, via active Ethernet port.
System requirements for CLI
Connection through Data 1 port locally (UART):
* PC equipped with terminal emulator application supporting VT100 /
102 or ANSI protocols, e.g. Hyper Terminal, PuTTY or Tera Term.
* RS232-cable (type Teleste CIC506)
Connection through Ethernet port remotely (Telnet/SSH):
* PC equipped with terminal emulator application supporting Secure
Shell (SSH) network protocol, e.g. PuTTY or Tera Term.
* Ethernet-connection
