Tenda AC1200 User Manual

7
2.3 Web UI layout
The web UI of the router consists of two sections, including the navigation bar and the
configuration area. See the following figure.
SN
Name
Description
❶
Navigation bar
It is used to display the function menu of the router. Users can select
functions in the navigation bar and the configuration page appears in the
configuration area.
❷
Configuration area
It is used to modify or view your configurations.
2
1

Tenda AC1200 Specifications

General

Data Transfer Rate	1200Mbps
Wireless Standard	IEEE 802.11ac/a/n 5GHz, IEEE 802.11b/g/n 2.4GHz
Frequency Bands	2.4GHz, 5GHz
Wireless Speed	300Mbps (2.4GHz) + 867Mbps (5GHz)
Antenna	4 x 5dBi external antennas
Security	WPA/WPA2-PSK
Button	WPS button, Reset button
DHCP Server	Support
