127
----End
If the rule is added successfully, it is displayed in the list below the Add button. See the following figure:
Verification
Enter Protocol name://WAN port IP address:External port in the address bar of a web browser on a computer
over the internet to access the resources on the web server. In this example, enter http://202.105.11.22.
If internet users still cannot visit the web server in LAN after the configuration, try the following solutions:
Ensure that the WAN IP address of the CPE is a public IP address, and the internal port you entered is correct.
Security software, antivirus software, and the built-in OS firewall of the computer may cause port forwarding
function failures. Disable them and try again.
Manually set an IP address and related parameters for the web server to avoid the service disconnection caused by
the dynamic IP address.
