67
6
Netw
ork
6.1
LAN Setup
6.1.1
Overview
Log in to the web UI of the CP
E, and choose
Network
>
LAN Setup
t
o enter the page.
This
page
enables
you
to
view
the
MAC
address
of
the
LAN
port,
and
set
up
the
device
name,
and
type
of
obtaining an IP addr
ess and related par
ameters.
Par
ameter
s
Description
Name
Description
MAC Address
It specifies the MAC address of LAN port.
The default SSID of the CPE is
Tenda_XXXXXX
, and XXXXXX is the last six characters of this MAC
address.
IP Address Type
It specifies the type of obtaining an IP address. The default is
Static IP Address
.
Static IP Address: Specify the IP address, subnet mask, default gateway, and DNS server IP
addresses manually.
73
75
