65
5.3.5
ARP Table
It specifies the current ARP
table of the CPE.
Par
ameter
s
Description
Name
Description
IP Address
It specifies the IP address of the host in the APR table.
MAC Address
It specifies the MAC address corresponding to the IP address.
Interface
It specifies the interface used to communicate with the host.
5.3.6
Routing Table
It specifies the destination ne
tworks that the CPE can access.
71
73
