The following form shows the configuration on the switch:
Ports of the Switch
VLAN ID (Allow the packets belonging to
the following VLANs to access)
Type of Port
PVID
Uplink port (Connected to a
router)
1,10,20
Trunk
1
Port 1 (Connected to CPE1)
1,10
Trunk
1
Port 3 (Connected to CPE2)
1,20
Trunk
1
Keep the default settings for the parameters which are not mentioned here. Refer to the user guide of the switch
for details.
The following form shows the configuration on the router:
Port of the router is
connected to
VLAN ID (Allow the packets belonging to
the following VLANs to access)
Type of Port
PVID
The switch
10, 20
Trunk
1
Refer to the user guide of the router for details.
----End
Verification
If the router enables two DHCP servers which belong to VLAN10 and VLAN20 respectively, the first device
connected to the CPE obtains an IP address and related parameters from the DHCP server belonging to VLAN10,
and the second device obtains these parameters from the DHCO sever belonging to VLAN20.
