Tenda O1 User Manual

127
----End
If the rule is added successfully, it is displayed in the list below the Add button. See the following figure:
Verification
Enter Protocol name://WAN port IP address:External port in the address bar of a web browser on a computer
over the internet to access the resources on the web server. In this example, enter http://202.105.11.22.

If internet users still cannot visit the web server in LAN after the configuration, try the following solutions:

Ensure that the WAN IP address of the CPE is a public IP address, and the internal port you entered is correct.

Security software, antivirus software, and the built-in OS firewall of the computer may cause port forwarding
function failures. Disable them and try again.

Manually set an IP address and related parameters for the web server to avoid the service disconnection caused by
the dynamic IP address.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
