Tenda O1 User Manual

85
Parameters Description
Name
Description
Authentication Type
It specifies the authentication type for the WEP security mode. The options include Open and
Shared. The options share the same encryption process.
Open: It specifies that authentication is not required and data exchanged is encrypted using WEP.
In this case, a wireless client can connect to the wireless network corresponding to the selected
SSID without being authenticated, and the data exchanged between the client and the network is
encrypted in WEP security mode.
Shared: It specifies that a shared key is used for authentication and data exchanged is encrypted
using WEP. In this case, a wireless client must use a preset WEP key to connect to the wireless
network corresponding to the selected SSID. The wireless client can be connected to the wireless
network only if they use the same WEP key.
Default Key
It specifies the WEP key for the Open or Shared encryption type.
For example, if Default Key is set to Security Key 2, a wireless client can connect to the wireless
network corresponding to the selected SSID only with the password specified by Security Key 2.
Key 1/2/3/4
Enter WEP key. You can enter four keys, but only the key specified in the Default Key takes effect.
ASCII
It indicates that a key selected for the Open or Shared authentication type contains hexadecimal
characters.
5 or 13 ASCII characters are allowed in the key.
Hex
It indicates that a key selected for the Open or Shared authentication type contains hexadecimal
characters.
10 or 26 hexadecimal characters (range: 0-9, a-f, and A-F) are allowed in the key.
WPA-PSK, WPA2-PSK, and Mixed WPA/WPA2-PSK
Parameters Description
Name
Description
Security Mode
It indicates the personal or pre-shared key security mode, including WPA-PSK, WPA2-PSK, and
Mixed WPA/WPA2-PSK.
WPA-PSK: It indicates that the wireless network corresponding to the selected SSID is encrypted
using WPA-PSK.
WPA2-PSK: It indicates that the wireless network corresponding to the selected SSID is encrypted

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
