Tenda PON ONT HG9 - 2.2 Logout; 2.3 Web UI layout

Web UI
13
2.2 Logout
The ONT logs you out when you:
− Click the Logout button on the upper-right corner of the web UI, or click Logout in
Admin > Logout.
− Perform no operation within 20 minutes.
2.3 Web UI layout
The web UI of the ONT is composed of 4 parts, including the level-1 navigation tree, level-2
navigation tree, tab page area, and configuration area. See the following figure.
No.
Name
Description
❶
Level-1 navigation tree
The navigation bars and tab pages display the function menu of the
ONT. When you select a function in the navigation bar, the
configuration of the function appears in the configuration area.
❷
Level-2 navigation tree
❸
Tab page area
❹
Configuration area
It enables you to view and modify the configuration.
1
2
3
4
