WAN
40
Common WAN settings
This part shows the common settings in all types of WAN connections.
Parameter description
It specifies the WAN connection name which you set up.
You can add multiple WAN connections by clicking the drop-down list and choose new
link. After configuring required parameters, you can click Apply Change to save the
connections.
This parameter is generated automatically after you create a new link and cannot be
customized. A maximum of eight links can be created here.
If the WAN connection you want to set up includes VLAN information, you can select
Enable VLAN and set the VLAN ID as required.
This parameter is available only when the Enable VLAN function is enabled. It specifies
the 802.1P priority. Data with a larger priority value takes a higher priority to be
processed.
Multicast Vlan ID:
[1-4094] (HG6)
This VLAN ID must already exist in 802.1Q VLAN and only ports in this VLAN can
forward multicast packets.
