Tenda TEG3224P User Manual

User Guide
12
3.2 Login through Console Port
3.2.1 Preparation
Item
Caption
PC
With the Console port
Ethernet Cable
DB9-RJ45 Console Cable
3.2.2 Configuration Preparation
Step 1: Connect the console port from your PC (or other terminals) to the console port on the switch.
Step 2: Run terminal program (for example, terminal in Windows 3.X, Hyper Terminal in Windows
9X/Windows 2000/Windows XP, an example of Windows XP is described below) on PC and select the
console port that is connected to the switch and configure as below (Note: For win7 and win8 OS, you
need to download the Hyper Terminal programme first):
Bits per second: 115200; Data bits: 8; Parity: None; Stop bits: 1; Flow control: None.
