Tenda TEG3224P User Manual

User Guide
4
PoE
1. IEEE 802.3at and IEEE 802.3af;
2. Maximum power consumption: 385W;
Maintenance
Ping\Tracert\Cable check-up;
1.3.3 Package Contents
Please verify that the package contains the following items:
• Smart PoE Switch
• Power cord
• Install guide
• Console cable
• L-shaped Mounting Kit (2 brackets, screws)
• Four footpads
1.4 Device Hardware Interfaces
1.4.1 LEDs
The following table explains LED designations.
LED
Number
Color
Status
Description
POWER
1
Green
Off
Improper connection to power supply.
Solid
Proper connection to power supply.
SYS
1
Green
Off
System is functioning improperly.
Solid
System is functioning improperly.
Blinking
System is functioning properly.
PoE-MAX
1
Green
Off
Power available for additional PDs.
Solid
Reaching max power budget (354.2W)
and no more power available for another
new PD.
Link/Act 1-24
24
Orange
Off
An invalid link is established.
Solid
A valid link is established.
Blinking
Transmitting packets.
PoE 1-24
24
Green
Off
The PoE powered device (PD) is connected
and the port is supplying power
successfully.
Solid
No PoE-powered device (PD) connected.
SFP1 - SFP4
4
Green
Solid
Packet transmission or a valid link is
established on the port.
Off
An invalid link is established on the port.
1.4.2 Interfaces
1.4.2.1 Console Port
This switch, with an RS232 asynchronous console port, can be used for connecting PCs to test, configure,
