The operator must tell the system which
outrigger position is in use.
Start the choice by pressing the
outrigger
push button
(item 22).
The outrigger selection will automatically
move on to the next selection.
EXAMPLE:
From fully extended to half extended, or
from half-extended to fully retracted and
then back to fully extended with each push
of the button. If no other selections are
available, the message "No other chassis
options" will appear on the information
screen (item 1).
TEST
6
23,500
i2,300
44.8
62.7
26.4
1
22
