Maintenance
TA9 & TA10 Dumper 0803-3 December 2010 9-14
Fuel System
Diesel Fuel Level
• Check the diesel fuel level reaches the indicated maximum
level on the tank mounted level gauge (A). The gauge
markings indicate when the tank is Empty, half full or Full.
• To refill, remove the large filler cap (B) and pour the
recommended grade of fuel through the fuel strainer inside
the filler neck. NEVER overfill the fuel tank.
• When refuelling never leave the engine running
• Ensure the engine is cool, the machine is in a well ventilated
area and always use clean fuel from a clean container.
Fuel/Water Separator
To drain the separator (A)
• Remove the bleed screw (B) and discard the washer.
• Place a receptacle of suitable capacity under the tap (C) of
the separator, open the tap and allow contaminated fuel to
drain.
• Close the tap (C) and re-fit the bleed screw (B) using a new
washer.
b
When Refuelling Stop the Engine and Beware of Naked
Flames, Grinding Sparks etc.
