7-11 TA9 & TA10 Dumper 0803-3 December 2010
Operating Instructions
Towing Or Recovery
When towing or recovering the machine it is essential that the
top driveshaft between the transfer box and the gearbox is
disconnected to prevent damage to the gearbox.
Note that the parking brake will be inoperative when the drive
shaft is disconnected. Before removing the driveshaft it will be
necessary chock the wheels of the machine to prevent
movement.
A suitable rope or chain attached; using a ‘D’ link, to one of the
front lashing points or the rear tow hitch (A) should be used for
towing the dumper.
Towing
The machine may be towed for a maximum distance of 1 mile
(1.6 kilometres) at speeds not exceeding 15 mph (25kph).
NOTICE
To prevent oil starvation and possible seizure of the
transmission whilst towing vehicle, it is imperative that
the top drive shaft is disconnected. Failure to observe this
precaution may result in extensive damage to
transmission.
b
When the driveshaft is disconnected the parking brake
will not operate. The wheels must be chocked to prevent
movement.
b
The rope, chain etc. must be of adequate strength for the
weight of the dumper and its load. All bystanders must be
kept well clear when towing or recovering.
