Description
TA9 & TA10 Dumper 0803-2 November 2009 5-22
Engine Canopy Doors
The engine canopy door (C) hinges, are fitted vertically causing
the door to open forwards.
The door (C) is opened by lifting the catch handle (A) from edge
(D). To close the door (C), firmly push the door (C) into the
closed position.
A lock (B) is fitted to prevent unauthorised access to the engine
compartment.
Tow Hitch
The dumper has not be designed for, and we do not
recommend its use as a towing vehicle but if so used always
make sure the weight of any trailer and its load does not
exceed half the rated payload of the dumper.
It is important that if used for towing:
• .The skip is loaded with half the rated payload to provide
adhesion when braking.
• The machine is NEVER driven down gradients as “jack
knifing” may occur.
• Only first gear is used and the machine is never driven on or
across inclines.
• The grip clip (B) must be positioned through the towing pin
(C) when the trailer etc. has been attached to the bracket (A).
