5-15 TA9 & TA10 Dumper 0803-2 November 2009
Description
Start/Stop Switch
The Start/Stop Switch (A) is operated by removable key. The
engine will not start unless the operator is sitting on the seat.
The switch has 4 positions:-
- O - Off/Neutral
-1 - Run
-2 - Heat
-3 - Start
Forward / Reverse Switch
When the machine is not being used or driven the Forward/
Reverse Switch (A) should always be in position '0' to prevent
accidental movement.
Forward/Reverse Positions and Actions
0 = Neutral
1 = Forward
2 = Reverse
If the handbrake is ‘ON’ when forward or reverse is selected a
warning buzzer will sound.
If a reverse alarm option is fitted this will also sound when
reverse is selected regardless of the handbrakes status. See
“Audible Warning, Hourmeter and Reverse Bleeper” section on
page 5-18.
