Terex TA10 - Dimensions

10-1 TA9 & TA10 Dumper 0803-4 July 2011
Specifications
Dimensions
Dimensions and Specification
Dimensions =
mm (ins)
A B C D E F G
H
ROPs Beacon
I
across
tyres
J
across
skip
Weight
(wet)
kg (lbs)
TA9
2,670
(105.1)
1,722
(67.8)
420
(16.5)
2,450
(96.5)
4,330
(170.5)
338
(13.3)
2,532
(99.7)
3,282
(129.2)
3,537
(139.3)
2,380
(93.7)
2,500
(98.4)
4,875
(10747)
TA10
2,695
(106.1)
1,760
(69.3)
440
(17.3)
2,450
(96.5)
4,450
(174)
338
(13.3)
2,630
(103.5)
3.375
(132.9)
3,630
(142.9)
2,380
(93.7)
2,550
(100.4)
4,920
(10847)
)
*
+
-
)
,
0
/
.
p0515-002
