Terex TA10 User Manual

Specifications
TA9 & TA10 Dumper 0803-4 July 2011 10-6
Electric Circuit
Item Description Cable Colour Codes
1 Switch - Site Light (A=OFF - B=ON)
B Black
2 Front - Site lights
G Green
3 Rear - Site lights
K Pink
4 Button - Horn
LG Light Green
5 Horn
N Brown
6 Button - Transmission dump
O Orange
7 Switch - Seat Interlock
P Purple
8 Switch - Direction (A=Forward - B=Neutral - C=Reverse)
R Red
9 Reverse alarm
S Slate
10 Solenoid - Reverse drive
U Blue
11 Solenoid - Forward drive
T Turquoise
12 Accessory socket
W White
13 Beacon
Y Yellow
14 Switch - Beacon
15 Fuse - Inline 10amp
16 Fuse - Inline 10amp
17 Fuse - Inline 5amp
18 Fuel Pump
8005-0833B
