TL260
Operation
140 / 187
7
07_Operation_en.fm - V 0.1 - 14.4.11
15
Float position of lift frame TL02600273>
Fig. 7-17 Float position
Adjusting the impulse mode
Place the loading bucket on the floor.
Push joystick forwards beyond the pressure point.
J The float position is activated for as long as the joystick is held in the pressed
position.
Adjusting the continuous operation
Place the loading bucket on the floor.
Move the switch (2) to the rear switch position.
J The green indicator lamp lights up.
Push joystick forwards beyond the pressure point.
Joystick is automatically engaged in this position.
Exiting continuous operation
Exit continuous operation by returning the joystick to neutral or moving the
switch (2).
UNIDECK
UNIDECK
P
-
+
HAZARD
P
AUTO
OFF
0
I
4560_7011_a
2
Note
The float position must always be disengaged unless operated. Move the
switch (2) to position "1".
