TL260
Specifications
164 / 187
9
09_Specifications_en.fm - V 0.1 - 14.4.11
17
9.3 Dimensions and weights
J Specifications refer to general-purpose bucket and 20.5 R 25 tires
Tab. 9-9 Dimensions and weights
J
Specifications refer to general-purpose bucket and 20.5 R 25 tires
J Stability conforms to DIN 24094
Dimensions and weights
Operating weight, standard equipment
1)
approx. 14,400 kg
Total length, standard bucket on ground (quick-
attach system / directly mounted)
7,320 / 7,230 mm
Total width 2,500 mm
Total height (cab roof) 3,260 mm
Wheel base 3,100 mm
Track width FR / RR 1,900 mm
Rear overhang angle 35°
Ground clearance below propeller shaft 620 mm
Turning radius at outside edge of bucket in transport
position (quick-attach system/ directly mounted)
6,200 / 6,150 mm
Turning radius at inside edge of tires 3,060 mm
1)
according to ISO 6016
Front loader installation Quick-attach
system
Direct
mounting
Width of bucket 2,500 mm 2,500 mm
Capacity to DIN/ISO 7546 (max. density =
1.8 t/m³)
approx. 2.5 m
3
approx. 2.6 m
3
Payload in bucket 4,500 kg 4,680 kg
Dump height at 45° dump angle 2,850 mm 2,920 mm
Dump reach at max. dump height 1,180 mm 1,100 mm
Max. bucket hinge pin height 4,040 mm 4,040 mm
Reset angle 51° 51°
Dump angle at max. dump height 45° 45°
Digging depth, horizontal bucket 100 mm 70 mm
Lift capacity at ground level according to
ISO 8313
141.0 kN 141.0 kN
Ripping force at cutting edge of bucket
1)
119.9 kN 121.5 kN
Tipping load, straight 10,360 kg 10,720 kg
Tipping load, articulated 9,040 kg 9,360 kg
